High-Efficincy
Air-Cooler
Selection Solution
A professional selection tool based on the topchill product manual
Topchill Air Cooler Exchangers Products Series
We offer a variety of types of cold air machines to meet the cooling needs of different scenarios
TC High-Efficincy Commercial Air Cooler
Suitable for the small and medium-sized cold storage. The compact design allows for increased utilization of the cold storage。
- 53 standard models，Capacity：0.9KW-23KW
- with a range of applications from +15℃ to-30℃
- European standard design，High-efficiency internal thread copper tube，Sine-wave pattern aluminum alloy fins
- According to the application requirements of coldstorage, the series of heat exchangers are divided into the following three categories:
- TCH: high temp. (≥-5℃)，with 4mm fin spacing.
- TCM: Med temp.(≥-18℃)，with 6mm fin spacing.
- TCL: Low temp.(≥-30℃)， with 8mm fin spacing.
TI High-Efficincy Industrial Air Cooler
Suitable for the large and medium-sized cold storages, cold chain logistics center，Efficient and reliable。
- 42 standard models，Capacity：10.1KW-121KW
- with a range of applications from +15℃ to-30℃
- The high-tensile air coil design ensures a long range and minimal air volume loss
- According to the application requirements of coldstorage, the series of heat exchangers are divided into the following three categories:
- TIH: high temp. (≥-5℃)，with 4mm fin spacing.
- TIM: Med temp.(≥-18℃)，with 6mm fin spacing.
- TIL: Low temp.(≥-30℃)， with 8mm fin spacing.
TIF Blast Freeze Refrigeration Air Cooler
It is suitable for low-temperature, high-humidity and quick-freezing environments, effectively extending the defrosting interval.
- 17 standard models，Capacity：11.5KW-117.2KW
- Variable sheet distance design：16mm-8mm
- Inner rotor axial flow fan, with large air volume and high air pressure
- Customized coils and installation forms can be produced according to customer requirements
TA High-Efficincy Angled Unit Cooler
Suitable for cooling equipment installed in warehouses with limited dimensions，Air is discharged from the single-sided fin side or the inclined end motor side。
- 14 standard models，Capacity：2KW-8KW
- With a range of applications from 0℃ to-18℃
- European standard design，High-efficiency internal thread copper tube，Sinusoidal wave structure fins
- According to the application requirements of coldstorage, the series of heat exchangers are divided into the following two categories:
- TAH: high temp. (≥-5℃)，with 4mm fin spacing.
- TAM: Med temp.(≥-18℃)，with 6mm fin spacing.
TM High-Efficincy dual discharge Unit Cooler
Suitable for food operation and processing rooms，Uniform air supply，Low noise。
- 18 standard models，Capacity：3KW-30KW
- With a range of applications from 0℃ to-18℃
- European standard design，High-efficiency internal thread copper tube，Sinusoidal wave structure fins
- According to the application requirements of coldstorage, the series of heat exchangers are divided into the following two categories:
- TMH: high temp. (≥-5℃)，with 4mm fin spacing.
- TMM: Med temp.(≥-18℃)，with 6mm fin spacing.
Unit Cooler Correction Factor Reference
The cooling capacity correction coefficients under various working conditions are used to accurately calculate the actual cooling effect
制冷剂修正系数
| 制冷剂 | 修正系数 (F1) |
|---|---|
| R404A | 1 |
| R507 | 1 |
| R22 | 0.97 |
| R134a | 0.93 |
| R407C | 0.98 |
翅片类型修正系数
| 翅片类型 | 修正系数 (F2) |
|---|---|
| 铝翅片 | 1 |
| 亲水铝翅片 | 0.97 |
| 喷涂铝翅片 | 0.92 |
| 铜翅片 | 1.05 |
SC1工况修正系数
蒸发温度(Evap)0°C, 温差(TD)10K, 进风温度10°C
| 蒸发温度 (°C) | TC系列 | TI系列 |
|---|---|---|
| -8 | 0.86 | 0.88 |
| -6 | 0.89 | 0.91 |
| -4 | 0.93 | 0.94 |
| -2 | 0.96 | 0.97 |
| 0 | 1 | 1 |
| 2 | 1.04 | 1.03 |
| 4 | 1.08 | 1.07 |
| 6 | 1.12 | 1.11 |
| 8 | 1.16 | 1.15 |
| 12 | 1.2 | 1.19 |
SC2工况修正系数
蒸发温度(Evap)-8°C, 温差(TD)8K, 进风温度0°C
| 蒸发温度 (°C) | TC系列 | TI系列 |
|---|---|---|
| -14 | 0.88 | 0.93 |
| -12 | 0.92 | 0.95 |
| -10 | 0.96 | 0.97 |
| -8 | 1 | 1 |
| -6 | 1.04 | 1.03 |
| -4 | 1.08 | 1.07 |
| -2 | 1.12 | 1.1 |
| 0 | 1.17 | 1.14 |
| 2 | 1.22 | 1.17 |
| 4 | 1.26 | 1.21 |
| 6 | 1.31 | 1.25 |
| 8 | 1.36 | 1.28 |
| 12 | 1.4 | 1.35 |
SC3工况修正系数
蒸发温度(Evap)-25℃, 温差(TD)7K, 进风温度-18℃
| 蒸发温度 (°C) | TC系列 | TI系列 |
|---|---|---|
| -40 | 0.78 | 0.86 |
| -36 | 0.85 | 0.9 |
| -30 | 0.92 | 0.96 |
| -25 | 1 | 1 |
| -20 | 1.08 | 1.05 |
| -15 | 1.16 | 1.11 |
| -12 | 1.21 | 1.15 |
SC4工况修正系数
蒸发温度(Evap)-31℃, 温差(TD)6K, 进风温度-25℃
| 蒸发温度 (°C) | TC系列 | TI系列 |
|---|---|---|
| -47 | 0.7 | 0.82 |
| -44 | 0.76 | 0.86 |
| -40 | 0.84 | 0.91 |
| -36 | 0.91 | 0.95 |
| -31 | 1 | 1 |
| -25 | 1.08 | 1.05 |
| -20 | 1.15 | 1.11 |
SC5工况修正系数
蒸发温度(Evap)-40℃, 温差(TD)6K, 进风温度-34℃
| 蒸发温度 (°C) | TC系列 | TI系列 |
|---|---|---|
| -52 | 0.88 | 0.93 |
| -50 | 0.81 | 0.85 |
| -47 | 0.87 | 0.9 |
| -44 | 0.93 | 0.94 |
| -40 | 1 | 1 |
| -36 | 1.09 | 1.05 |
| -31 | 1.18 | 1.1 |
| -25 | 1.28 | 1.16 |
更多工况修正系数可参考天奇环境冷风机产品手册
下载完整产品手册Contact Us
If you need more product information or professional selection advice, please feel free to contact us at any time
